Fit For BMW X3 MP 4Pot Brake Caliper Kits Red Color 374MM Discs Replacement Pads

Fit For Brembo GT6 Caliper Brackets Color Can Customized For Toyota Honda Mercedes Benz

Specification of Fit Brembo GT6 Bracket

The car caliper bracket is a component that connects the modified brake caliper to the car. Each set of car brake bracket is customized based on the vehicle model, caliper model, and disc data.

Therefore, to perfectly fit the entire brake system into the wheel, car caliper brackets require a precise data. The car caliper brackets is one of the essential components in a modified brake kit.  Both are precision machined using CNC machines to achieve high accuracy.

There are various styles available, and surface color can be done in multiple colors, providing options for clients to choose.

The materials used for car caliper brackets mainly include the following:

1. Aluminum alloy 6061-T6: It consists of 97.9% aluminum, 1% magnesium, 0.6% silicon, 0.28% copper, and 0.2% chromium. Aluminum alloy has the advantages of high strength, lightweight, and good heat dissipation, making it highly advantageous for the brake system. Therefore, aluminum alloy is commonly used in most cases.

2. Aluminum alloy T-7075: It primarily consists of 90% aluminum and 5.6% zinc, with additional elements such as 2.5% magnesium, 1.6% copper, and 0.23% chromium, along with trace amounts of silicon, manganese, titanium, and other metals. Overall, the strength of 7075 aluminum alloy is higher than that of 6061 aluminum alloy because 7075 contains approximately 8% less aluminum than 6061.

3. 45# steel: This type of steel is typically applied to bridge codes with extreme data requirements, such as those with fewer threads and shorter lengths that require overall strength, which cannot be achieved by aluminum alloy.

Sandblasting involves the impact and cutting action of abrasives on the surface of the workpiece, resulting in a certain degree of cleanliness and different levels of roughness. This process improves the mechanical properties of the surface, enhances the fatigue resistance of the workpiece, increases adhesion between the workpiece and the coating, and prolongs the durability of the coating.

Anodizing provides protective, decorative, and insulating properties, improves adhesion with organic coatings, and enhances adhesion with inorganic coatings. The thin film of metal oxide formed changes the surface state and properties, such as surface coloring, improved corrosion resistance, increased wear resistance and hardness, and protection of the metal surface.

The surface color of car caliper brackets normal is black. However, clients who seeking individuality can customized the color of the car caliper brackets to match the wheel or whole car color.
